HPM100/AMC
5-Year Warranty
    Speed range：0.1-150 rpm
    Flow range：0.0002-65 mL/min
Optional pump head：
AMC
Online consultation
Download

Product Introduction

  • The pump shell protection level is IP66, specially designed for industrial environments. It features 6 types of sealing structures that withstand extreme humidity and temperature conditions, ensuring long-term stable operation.
  • The intelligent control system supports both transferring and dispensing functions.
  • The 4.3-inch touch screen enables simplified operation, parameter configuration, and calibration.
  • Circuit isolation is achieved both inside and outside the external control interface.
  • Aluminum alloy body with excellent heat dissipation performance.
  • Three levels of permissions management function.

Technical Parameter

EMC Standard IEC 61000-6-2/IEC 61000-6-4/IEC 61000-3-2/IEC 61000-3-3
Housing material Aluminum alloy
Speed range 0.1-150 rpm
Speed adjustment resolution 0.01 rpm
Display 4.3-inch industrial-grade color LCD screen
Control modes Touch screen, mechanical keypad, external control signal control, communication control
Working modes Transferring mode, dispensing mode (Fixed volume, dispensing, speed dispensing)
Transferring mode Continuous operation at set flow rate and speed
Dispensing mode Dispensing:Set volume, time, repeat numbers, pause time
Dispensing:Set volume, flow rate, repeat numbers, pause time
Speed dispensing:Set speed (rpm), time, repeat numbers, pause time
Dispensing volume range 0.1ml-9999L
Dispensing time range 0.1s-9999h
Pause time range 0.5s-9999h
Repeat numbers 1-9999 times, 0 means unlimited times
Calibration Automatic calibration after inputting actual running liquid volume
Back suction angle 0-360°
Communication interface RS485
Communication protocol Modbus protocol (RTU mode)
External control speed signal 0-5V, 0-10V, 4-20mA (optional)
External control signal input Active switch signal (5-24V) controls start/stop, direction; Passive switch signal controls start/stop
Signal output Open collector output operation status; 4-20mA output
Open cover to stop pump function Prevent misoperation and effectively protect user safety(Depend on pump head)
Three levels of permissions Reasonable configuration of operation permissions
Drive dimension 274×160×221 mm (L×W×H)
Power supply AC110-220V±10% 50/60Hz
Rated power 110W
Working environment 0-40°C
Drive weight 6.2kg
Relative humidity <100%
Protection level IP66

Pump Head Parameter

Pump Head Tubing Size Speed Flow rate(mL/min)
AMC1-AMC12(10) ID: 0.13-3.17mm, Wall: 0.8-1mm 0.1-150rpm 0.0002-48
AMC1-AMC12(6) ID: 0.13-3.17mm, Wall: 0.8-1mm 0.0002-65

OSD

Qualification Certificate

Dimension（Unit：mm）
